If jQuery has one strength, it’s the library’s fantastic ability to manipulate HTML objects. Built into the library are easy to use methods for moving objects, adjusting CSS and tag attributes, changing visibility of anything on the page, and many more. To sweeten the deal, jQuery includes animation effects that allow you to transition any object from one state to another in an aesthetic way that only takes a line or two of code.
With these ideas in mind, it’s a small wonder that many jQuery plugins were developed with the intention of easily introducing pretty slideshows to display and rotate series of images. However, if you look around long enough, you’ll be facing a frustrating truth—almost none of these slideshow plugins utilize the idea of rotating CSS backgrounds.
Right now you may be telling yourself, “Self, using rotating CSS backgrounds instead of image tags for a jQuery slideshow is a bad idea.” Well, surprise, this article is a dream within a dream within a dream to convince you of the opposite. When you wake up, you’ll have a changed mind, and better yet, you’ll think it was your idea.
Best practices in HTML, CSS, and Javascript
Let’s have an honest discussion about HTML markup and Javascript. As CSS became a dominant force in shaping the appearance of valid HTML in the 2004 and on, it became more important to structure markup in a meaningful way. Using tables for layout has gone the way of the dinosaurs, DIV overload is now taboo, and designers are utilizing more intelligent information structure in their markup. Somewhere in all this sanity, jQuery has made us a little bit crazy.
“Look how easy it easy to create an image slider for my page’s mast head!”
“But Brian, isn’t it foolish to make a mast head’s appearance reliant on an image tag rather than CSS?”
“Shut up, Self, just look at these animation effects. It’s so easy!”
“But Brian, what if you have 10 different images for a single mast head and jQuery doesn’t load properly or the user has Javascript disabled? Your page is going to look really funny with 10 versions of your mast head all displayed at the same time.”
“…screw those users…”
“This is not good practice, Brian.”
“But… but…”
“BE A CHAMPION!”
You get the idea. It’s not a good idea to use an image tag slider unless you’re looking for an alternative way of displaying structured content, such as a photo gallery. However, many designers use these convenient image sliders to display graphics better suited for CSS background use. Slackers.
Fear not, you can have your cake and eat it, too. All you need is jQuery and a bit of know-how. I’m here to provide the know-how, good buddy. Let’s do this—high five!
Creating an CSS background slider with jQuery
Step 1: Markup
We’ll start with the HTML markup and CSS. Our example will be a typical mast head that is of a fixed width and height in the body of the page:
[code lang=”xml”]
<div id="mast-head" style=”background: url(path/to/images/1.jpg) no-repeat; height: 300px; width: 300px;"></div>
[/code]
As always, we’ll include the jQuery library and provide a space for our Javascript code in the head of the page:
[code lang=”javascript”]
<script type="text/javascript" src="path/to/js/jquery.js"></script>
<script type="text/javascript">
$(document).ready(function(){
//code goes here
});
</script>
[/code]
The line of code $(document).ready(function(){}) is a way of telling your page to execute commands after the page has finished loading. Our script will go inside, just to be sure that our code doesn’t try to manipulate HTML objects that have not yet loaded.
Step 2: Preloading Images
One pitfall of dynamic CSS backgrounds is that when a background image is changed, the user will notice a ‘flicker’ as the new background is loaded on the page. We can avoid unintended visual discrepancies by preloading the images before the background-changing code that is executed.
[code lang=”javascript”]
var imgArr = new Array( // relative paths of images
‘path/to/images/1.jpg’,
‘path/to/images/2.jpg’,
‘path/to/images/3.jpg’,
‘path/to/images/4.jpg’
);
var preloadArr = new Array();
var i;
/* preload images */
for(i=0; i < imgArr.length; i++){
preloadArr[i] = new Image();
preloadArr[i].src = imgArr[i];
}
[/code]
Let’s break it down. First, we create an array that holds the relative paths to each image file that we want to include in our rotation. Next, we create another array which will hold Image objects. A Javascript Image object is a symbol of an HTML image element, and once you declare its source, it is cached by the browser. We can then create a loop that goes through our ‘relative path’ array and creates an Image object representing each image we want in our rotation. The source is assigned for each Image object, and viola, our CSS background images are preloaded and cached.
Step 3: Dynamic CSS changes and animation
All that’s left is to take our preloaded CSS background images and rotate them one at a time over a set interval. This can be accomplished with a small amount of code:
[code lang=”javascript”]
var currImg = 1;
var intID = setInterval(changeImg, 6000);
/* image rotator */
function changeImg(){
$(‘#mast-head’).animate({opacity: 0}, 1000, function(){
$(this).css(‘background’,’url(‘ + preloadArr[currImg++%preloadArr.length].src +’) top center no-repeat’);
}).animate({opacity: 1}, 1000);
}
[/code]
There isn’t a lot of code, but there is a lot going on here. First, we set a variable that will map which image in the ‘preloaded’ array is being displayed. Next, we set the interval at which our changeImg() function is executed. Remember, Javascript measures time in milliseconds, so our argument of 6000 is equal to 6 seconds.
Finally, we create the changeImg() function that will change the CSS background image of the element we dictate while animating the process. The logic is to use jQuery’s animate() method to transition from one CSS state to another over a set amount of time. In our case, we’re changing the opacity to 0 over a 1 second period. Then, we change the background image of the #mast-head element with jQuery’s css() function and a bit of fancy array element selection. At the end, we again use animate() to bring the element’s opacity back to 1. Essentially—fade out, change background, fade in. Neato!
Here’s how your final script will look:
[code lang=”javascript”]
<script type="text/javascript" src="path/to/js/jquery.js"></script>
<script language="JavaScript" type="text/javascript">
$(document).ready(function(){
var imgArr = new Array( // relative paths of images
‘path/to/images/1.jpg’,
‘path/to/images/2.jpg’,
‘path/to/images/3.jpg’,
‘path/to/images/4.jpg’
);
var preloadArr = new Array();
var i;
/* preload images */
for(i=0; i < imgArr.length; i++){
preloadArr[i] = new Image();
preloadArr[i].src = imgArr[i];
}
var currImg = 1;
var intID = setInterval(changeImg, 6000);
/* image rotator */
function changeImg(){
$(‘#masthead’).animate({opacity: 0}, 1000, function(){
$(this).css(‘background’,’url(‘ + preloadArr[currImg++%preloadArr.length].src +’) top center no-repeat’);
}).animate({opacity: 1}, 1000);
}
});
</script>
[/code]
True to form, this jQuery demo has a lot of things happening in a small amount of space. Use this portable little script for any number of projects, and remember, only use an image tag slider if it makes sense to do so! In many cases, dynamic CSS background changes are best practice. Check out this script in action.
Until next time, amigos, happy programming.
*kick*
